Hot-selling Plastic Disposable Glass Machine - Low price Full Auto Disposable PS PVC APET Fast Food Container Box Production Line Vacuum Forming Machine – GTMSMART

We insist on offering good quality generation with very good business enterprise concept, honest income as well as best and fast assistance. it will bring you not only the premium quality product or service and huge profit, but probably the most significant is usually to occupy the endless market for Lid Thermoforming Machine , China Thermoforming Machine , Thermoforming Machine For Biscuit Tray , Teamwork is encouraged at all levels with regular campaigns. Our research team experiments on various developments in the industry for improvement in the products.

---

Hot-selling Plastic Disposable Glass Machine - Low price Full Auto Disposable PS PVC APET Fast Food Container Box Production Line Vacuum Forming Machine – GTMSMART Detail:

From the past few years, our firm absorbed and digested sophisticated technologies equally at home and abroad. Meanwhile, our organization staffs a group of experts devoted into the growth of Low price Full Auto Disposable PS PVC APET Fast Food Container Box Production Line Vacuum Forming Machine, We wish to just take this opportunity to ascertain long-term enterprise relationships with clients from all over the earth.
From the past few years, our firm absorbed and digested sophisticated technologies equally at home and abroad. Meanwhile, our organization staffs a group of experts devoted into the growth of China Vacuum Forming Equipment, Fast Food Container Box Production Line, fast food container vacuum forming machine, If you are for any reason unsure which product to select, do not hesitate to contact us and we are going to be delighted to advise and assist you. This way we are going to be providing you with all the knowledge needed to make the best choice. Our company strictly follows “Survive by good quality, Develop by keeping good credit. ” operation policy. Welcome all the clients old and new to visit our company and talk about the business. We have been looking for more and more customers to create the glorious future.

Thermoplastic Vacuum Forming Machine Description

Vacuum forming, also known as thermoforming, vacuum pressure forming or vacuum molding, is a procedure in which a sheet of heated plastic material is shaped a certain way.

PLC Automatic Plastic vacuum Forming Machine: Mainly for the production of variety plastic containers ( egg tray, fruit container, package containers, etc) with thermoplastic sheets, such as APET, PETG, PS, PVC,etc.

Product Advantages

1. This Vacuum Forming Machine Utilizes PLC control system, servo drives upper and lower mould plates, and servo feeding, which would be more stable and precision.

2. Human-computer interface with high definition contact-screen, which can monitor the operation situation of all parameter setting.

3. The Plastic vacuum forming machine Applied self-diagnosis function, which can real-time display breakdown information, easy to operate and maintenance.
4. The pvc vacuum forming machine can store several product parameters, and the debugging is quick when producing different products.

Automatic Vacuum Forming Machine Specifications

Model	HEY05A	HEY05B
Control	Air Cylinder	Servo
Forming Area（L*W）	1350*760 mm
Option Customized Forming Area（L*W）	1220*760/900mm, 1350*900mm, 1500*760/900mm
Whole Machine Power	Max. 50kw
Heating Power	Max. 40kw
Average Power Consumption	About 25kw
Heating Method	Infrared-radiation Heating
Work Frequency	4-24 times/min
Forming Height	Max. 240mm (Male Mould), Max. 200(Female Mould)
Sheet Thickness	0.1-2.5 mm
Sheet Width	450-800mm
Air Compressor	0.6-0.7 Mpa
Air Supply Quantity	1.5-2 m3/min
Vacuum Flow Rate	100 m3/hour
Power	3kw
Ultimate Vacuum	5mbar
Water Supply	350kg/h
Power Supply	Three Phase Four Lines 380V 50/60HZ
Machine Dimensions	8900*1800*2600mm
Whole Machine Weight	Around 4500 kg

From the past few years, our firm absorbed and digested sophisticated technologies equally at home and abroad. Meanwhile, our organization staffs a group of experts devoted into the growth of Low price Full Auto Disposable PS PVC APET Fast Food Container Box Production Line Vacuum Forming Machine, We wish to just take this opportunity to ascertain long-term enterprise relationships with clients from all over the earth.

China Vacuum Forming Equipment, Fast Food Container Box Production Line, fast food container vacuum forming machine, If you are for any reason unsure which product to select, do not hesitate to contact us and we are going to be delighted to advise and assist you. This way we are going to be providing you with all the knowledge needed to make the best choice. Our company strictly follows “Survive by good quality, Develop by keeping good credit. ” operation policy. Welcome all the clients old and new to visit our company and talk about the business. We have been looking for more and more customers to create the glorious future.

---

Product detail pictures:

---
