Hot Selling for Thermoforming Machine Manufacturers - Three Stations Negative Pressure Forming Machine HEY06 – GTMSMART
Hot Selling for Thermoforming Machine Manufacturers - Three Stations Negative Pressure Forming Machine HEY06 – GTMSMART Detail:
Application
Automatic Vacuum Forming Machine Mainly for the production of variety plastic containers ( egg tray, fruit container, package containers, etc) with thermoplastic sheets.
Vacuum Forming Machine Features
1.Mechanical, pneumatic, electrical integration. Each action program is controlled by PLC. Touching screen operation is simple and convenient.
2.Vacuum Forming In-mould Cutting.
3.Up and down moulds forming type.
4.Servo feeding, length step less adjusting, high speed accurately and stablity.
5.Blister Vacuum Forming Machine Up and down heater with two phases heating.
6.Electric heating furnace temperature control system adopts full computer intelligent automatic compensation control, partition control using digital input interface one by one, has the high precision fine-tuning, uniform temperature, heating up fast (only 3 minutes from 0-400 degrees), stability (not influenced by external voltage, temperature fluctuations no more than 1 degree), low energy consumption (energy saving about 15%), the furnace plate advantages for long life.
7.Forming and cutting station with open and close servo motor control, products with automatic tally output.
8.Products can be choosing by you to down stacking type,Or the manipulator is taken in the mold.
9.Plastic vacuum forming machine with product information and data memory function.
10.Feeding caterpillar width can be synchronization automatic or discretely electric adjusting.
11.Heater automatic shift out device.
12.Mechanical loading device, reduce workers labor strength.
Vacuum Forming Machine Technical Parameter
| Forming Area | 850x780mm |
| Max.Forming Depth | 150mm |
| Sheet thickness | 0.2-1.5mm |
| Work Efficiency | Max. 30 cycles/ Min |
| Air Pressure | 0.9mpa |
| Power Consumption | 50-70kw/h |
| Max. Sheet Width | 760mm |
| Suited Material | PP, PS, PET, PVC |
| Total Max. Power | 110 |
| Overall size(LxWxH）mm | 10040x2600x3200 |
| Total Weight (T) | 7 |
Product detail pictures:
