2022 Latest Design Paper Plate Ki Machine - 130-180 OZ Paper Bucket Making Machine HEY100-220 – GTMSMART Detail:

Features

1.Paper bucket machine with double turning plate, better for collecting the finished cup.

2.Ultrasonic sealing station for the cup side welding.

3.Two stations Hot air station for the bottom sealing

4.You can make cups of different size by changing molds.

5.Paper bucket making machine with PLC control, touch screen operation

6.Open cam system fully lubrication system in the machine.

7.Low operating cost, 1 worker can handle 1 machine.

Paper Bucket Forming Machine Technical Parameter

Model HEY100-200
Paper cup size 130-180oz or customize
Speed 25~~30 pcs/min
Max top diameter 220mm
Max bottom diameter 180mm
Min top diameter 120mm
Min.height 100mm
Min bottom diameter 90mm
Raw material 250~~380gsm, single or double PE coated paper
General power 15KW
Air consumption 0.5m³/min
Electricity 380V 3 phases
Weight 4500kg
Outline size (LxWxH)  3.98m×2.1m×1.9m

Product detail pictures:

2022 Latest Design Paper Plate Ki Machine -
 130-180 OZ Paper Bucket Making Machine HEY100-220 – GTMSMART detail pictures
